Benchmarking TensorFlow and TensorFlow Lite on Raspberry Pi 5

In regards to the benchmarking code

Benchmarking was accomplished utilizing TensorFlow, or for the {hardware} accelerated platforms that don’t help TensorFlow their native framework, utilizing the identical fashions used on the opposite platforms transformed to the suitable native framework.

For the Coral EdgeTPU-based {hardware} we used TensorFlow Lite, and for Intel’s Movidius-based {hardware} we used their OpenVINO toolkit. Benchmarks had been carried out twice on the NVIDIA Jetson Nano, first utilizing vanilla TensorFlow fashions, and a second time utilizing these fashions after optimization utilizing NVIDIA’s TensorFlow with TensorRT library.

Inferencing was carried out with the MobileNet v2 SSD and MobileNet v1 0.75 depth SSD fashions, each fashions educated on the Frequent Objects in Context (COCO) dataset. The 3888×2916 pixel take a look at picture was used containing two recognizable objects within the body, a banana🍌 and an apple🍎. The picture was resized right down to 300×300 pixels earlier than presenting it to the mannequin, and every mannequin was run 10,000 occasions earlier than a median inferencing time was taken.

ℹ️ Data The primary inferencing run, which may take as much as ten occasions longer resulting from loading overheads, is discarded from the calculation of the common inferencing time.

Whereas within the intervening years different benchmark frameworks have emerged which are arguably extra rigorous, the benchmarks offered listed here are supposed to replicate actual world efficiency. Numerous the opposite newer benchmarks measure the time to finish solely the inferencing stage. Whereas that’s a a lot cleaner (and shorter) operation than the timings measured right here — which embody arrange time — most individuals aren’t actually concerned with simply the time it takes between passing a tensor to the mannequin and getting a consequence. As a substitute they need end-to-end timings.

One of many issues that these benchmarks do not do is optimization. They take a picture, go it to a mannequin, and measure the consequence. The code is easy, and what it measures is similar to the efficiency a median developer doing the identical activity may get, quite than an skilled machine studying researcher than understands the complexities and limitations of the fashions, and how one can adapt them to particular person platforms and conditions.

Organising your Raspberry Pi

Go forward and obtain the newest launch of Raspberry Pi OS and arrange your Raspberry Pi. Except you’re utilizing wired networking, or have a show and keyboard hooked up to the Raspberry Pi, at a minimal you’ll must put the Raspberry Pi on to your wi-fi community, and allow SSH.

When you’ve arrange your Raspberry Pi go forward and energy it on, after which open up a Terminal window in your laptop computer and SSH into the Raspberry Pi.

ssh **@*********pi.native

When you’ve logged in you’ll be able to set up TensorFlow and TensorFlow Lite.

⚠️Warning Beginning in Raspberry Pi OS Bookworm, packages put in by way of pip should be put in right into a Python digital atmosphere. A digital atmosphere is a container the place you’ll be able to safely set up third-party modules in order that they received’t intrude along with your system Python.

Putting in TensorFlow on Raspberry Pi 5

Putting in TensorFlow on the Raspberry Pi is much more difficult than it was, as there is no such thing as a longer an official package deal obtainable. Nonetheless fortuitously there’s nonetheless an unofficial distribution, which a minimum of means we do not have to resort to constructing and putting in from supply.

sudo apt set up -y libhdf5-dev unzip pkg-config python3-pip cmake make git python-is-python3 wget patchelf
python -m venv --system-site-packages ~/.python-tf
supply ~/.python-tf/bin/activate
pip set up numpy==1.26.2
pip set up keras_applications==1.0.8 --no-deps
pip set up keras_preprocessing==1.1.2 --no-deps
pip set up h5py==3.10.0
pip set up pybind11==2.9.2
pip set up packaging
pip set up protobuf==3.20.3
pip set up six wheel mock gdown
pip set up opencv-python
TFVER=2.15.0.post1
PYVER=311
ARCH=`python -c 'import platform; print(platform.machine())'`
pip set up --no-cache-dir https://github.com/PINTO0309/Tensorflow-bin/releases/obtain/v${TFVER}/tensorflow-${TFVER}-cp${PYVER}-none-linux_${ARCH}.whl

Putting in TensorFlow Lite on Raspberry Pi 5

There may be nonetheless an official TensorFlow Lite runtime package deal obtainable for Raspberry Pi, so set up is far more easy than for full TensorFlow the place that possibility is not obtainable.

python -m venv --system-site-packages ~/.python-tflite
supply ~/.python-tflite/bin/activate
pip set up opencv-python
pip set up tflite-runtime

Operating the benchmarks

The benchmark_tf.py script is used to run TensorFlow benchmarks on Linux (together with Raspberry Pi) and macOS. This script can even used — with a TensorFlow set up which incorporates GPU help — on NVIDIA Jetson {hardware}.

supply ~/.python-tf/bin/activate
./benchmark_tf.py --model PATH_TO_MODEL_FILE --label PATH_TO_LABEL_FILE --input INPUT_IMAGE --output LABELLED_OUTPUT_IMAGE --runs 10000

For instance on a Raspberry Pi, benchmarking with the MobileNet v2 mannequin for 10,000 inference runs the invocation can be:

./benchmark_tf.py --model ssd_mobilenet_v2/tf_for_linux_and_macos/frozen_inference_graph.pb --label ssd_mobilenet_v2/tf_for_linux_and_macos/coco_labels.txt --input fruit.jpg --output output.jpg --runs 10000

This can output an output.jpg picture with the 2 objects (the banana and the apple) labelled.

The benchmark_tf_lite.py script is used to run TensorFlow Lite benchmarks on Linux (together with Raspberry Pi) and macOS.

supply ~/.python-tf-lite/bin/activate
./benchmark_tf_lite.py --model PATH_TO_MODEL_FILE --label PATH_TO_LABEL_FILE --input INPUT_IMAGE --output LABELLED_OUTPUT_IMAGE --runs 10000

⚠️Warning Fashions handed to TensorFlow Lite should be quantized. To take action the mannequin should be transformed to TensorFlow Lite format.

Getting the benchmark code

The benchmark code is now obtainable on GitHub. The repository consists of all of the assets wanted to breed the benchmarking outcomes, together with fashions, code for all of the examined platforms, and the take a look at imagery used. There may be additionally an ongoing dialogue about how one can enhance the benchmark to make it extra simply run on new {hardware}.
